Esocoo-15 Series 8 Holes SMT Splice Tape
Item No. : Esocoo-15 Series
Product Information

Place of Origin Guangdong, China

Brand Name Esocoo

Certification RoHS

Shipping Terms

Minimum Order Quantity: 1 box

Price: Negotiable

Delivery Time: 3-5 working days
Inquiry now

Detailed description

15 series 8 holes positioning universal splice tape, applicable to all size (8/12/16/24/32/44/56/72/88mm)carrier tapes

15 series splice tape is used for jointing carrier tapes in the SMT process. It is made of tapes and polyester film and release paper, and the tape is with superior adhesion. Available for all SMT machines.

Features:

1. Easy operation, no need to use auxiliary tools.
2. 8 hole positioning, with the help of positioning tool, more accurate jointing.
3. Using imported tape in high strength and high adhesive.
4. Automatic production, high production efficiency, and fast shipment.

5. Our factory independently develops glue and produces.

Part No.	Splice tape size	Qty/box	Carrier tape size
ESOCOO-1508	(4.5/4.2/2.3)x34mm	500pcs	08mm
ESOCOO-1512	(8.5/8/2.5)x34mm	500pcs	12mm
ESOCOO-1516	(12.5/12/2.5)x34mm	500pcs	16mm
ESOCOO-1524	(20/19.5/2.5)x34mm	250pcs	24mm

Application:

Used for jointing carrier tapes in the SMT process and Solving the connection

Accept OEM/ODM

Attentions:
Never touch adhesive tape side while using.
